Rastbolzen, Stahl, mit Zugöse, ohne Rastsperre

Product information "Rastbolzen, Stahl, mit Zugöse, ohne Rastsperre"

Holding magnets are a shielded magnet system. The arrangement of magnet and iron poles is called a sandwich magnet system. These holding magnets offer maximum holding forces even with small workpieces. Mounting options are press-fit or glue-in. * k1 is the maximum dimension by which the holding magnet can be shortened without losing its properties. ** When this holding magnet is installed directly in steel parts, a magnetic short-circuit occurs which leads to a reduction in holding force of up to 15 %. To avoid this, the distances k2 between the brass sheath and the steel part should be observed. These distances must also be maintained if the holding magnet has been shortened.

Anzugsmoment (Nm):	2
Federdruck Anfang (N):	3
Federdruck Ende (N):	12
Form:	D, mit Zugöse, ohne Kontermutter
Hersteller:	Ganter
SW (mm):	6
X-Line:	1
d1 (mm):	4
d2:	M 6
d3 (mm):	14
d4 (mm):	6
e (mm):	6,9
l1 (mm):	33,5
l2 (mm):	4
l3 (mm):	12
l4 (mm):	4,5
l5 (mm):	10
l6 (mm):	33,4
l7 (mm):	12,9
Material:	Stahl
